Multifunctional side pliers

Index: HT1P243
The universal 6 in 1 tool combining many functions enables the execution of various tasks conveniently and quickly. The tool lets you save space that would be needed for several different tools and reduce the weight of the tool bag.
A sharp and hard cutter, allows you to cut hard wire with a diameter of up to 17 mm.
The outer top surface of the cutter features a file that enables deburring and removing minor irregularities.
The press tool ensures permanent processing of 0.5-1.0 and 1.5-2.5 mm² electrical cable end-sleeves.
Thanks to precisely cut blades, the electrical wire insulation stripper does not damage the core from 1 to 2.6 mm.
High-quality, evenly hardened chromium-vanadium steel enables intensive use of the pliers for heavy-duty work requiring the application of high pressure.
The advanced induction heat treatment process provides the tool with high hardness that prevents the blades from becoming blunt. The well-thought-out geometry makes cutting easier.
Finely ground, hard working surfaces and teeth enable precise work.
The ergonomic handle linings, made of damage-resistant and soft TPU material, provide great comfort during long work.

Do you have any questions? Email us

informacja@hoegert.com

Description

Product description

The universal 6 in 1 tool combining many functions enables the execution of various tasks conveniently and quickly. The tool lets you save space that would be needed for several different tools and reduce the weight of the tool bag.
A sharp and hard cutter, allows you to cut hard wire with a diameter of up to 17 mm.
The outer top surface of the cutter features a file that enables deburring and removing minor irregularities.
The press tool ensures permanent processing of 0.5-1.0 and 1.5-2.5 mm² electrical cable end-sleeves.
Thanks to precisely cut blades, the electrical wire insulation stripper does not damage the core from 1 to 2.6 mm.
High-quality, evenly hardened chromium-vanadium steel enables intensive use of the pliers for heavy-duty work requiring the application of high pressure.
The advanced induction heat treatment process provides the tool with high hardness that prevents the blades from becoming blunt. The well-thought-out geometry makes cutting easier.
Finely ground, hard working surfaces and teeth enable precise work.
The ergonomic handle linings, made of damage-resistant and soft TPU material, provide great comfort during long work.

Characteristic

insulation stripping range AWG – 10 / 12 / 14 / 16 / 18;
insulation stripping range – 1 / 1.3 / 1.6 / 2 / 2.6 mm;
electrical terminal clamping range – 0.5-1.0 / 1.5-2.5 mm²;
jaw hardness – 43-48 HRC;
blade hardness – 58-63 HRC;
pliers material – CRV 60 steel;
handle lining material – TPE;
length – 200 mm;
width – 50 mm;
functions
1. cutting,
2. shortening,
3. shearing,
4. insulation stripping,
5. terminal connection,
6. filing.

Technical data

Grip type TPE
Material CrV
Warranty 25-years
